Датчик измерения Keyence CB-BD100
COM_VIRTUEMART_PRODUCT_NOSTOCK
Model | CB-BD100*1 | |
Type | BCD output unit | |
Display | LED display | POWER-ON LED |
Output terminal | BCD output | NPN open-collector output x 4 ports*2 |
Strobe output | NPN open-collector output x 4 outputs | |
OUT selection output | ||
Input terminal | Non-voltage input x 4 inputs | |
Power source | Supplied from the controller | |
Rating | Current consumption | 0.16 A or less |
Environmental resistance | Ambient temperature | 0 to +50 °C |
Relative humidity | 20 to 85 % RH (No condensation) | |
Weight | 800 g | |
*1 Up to 1 unit can be connected to the controller. NPN open-collector output rating: 30 mA max. (30 V max.), residual voltage of 0.5 V max. Non-voltage input rating: ON voltage of 1 V max., OFF current of 0.6 mA max. *2 Selectable from BCD output (29 bits, signed), binary output (25 bits, negative numbers are represented by the two’s complement), and judgment output. |
